- 12KW+30KWH
AC Input | |
Rated Input Voltage (VAC) | 220/230/240;L+N+PE |
Voltage Range (VAC) | 90~280+3 (normal mode); 170~280+3 (UPS mode) |
Frequency (Hz) | 50Hz/60Hz (Auto detection) |
AC Output | |
Rated Capacity (W) | 12000W |
Surge Power (VA) | 24000VA |
Voltage (VAC) | 220/230/240 |
Power Factor (PF) | 1 |
Frequency | 50/60Hz+0.1% |
Switch Time (ms) | 10(APP/UPS mode), 20(GEN mode) |
Wave Form | Pure Sine Wave |
Overload protection | (105% < load <110%) ±5%: report error and turn off the output after 5 minutes; (110% < load < 125%) ± 5%: report error and turn off the output after 10 seconds; Load >125% ±5%: report error and turn off the output after 5 seconds |
Max. Efficiency (Battery Mode) | 94%@48VDC |
Charger (PV / AC) | |
Solar Charger Type | Dual MPPTs |
Max PV input current / power | 1*MPPT: 27A/9KW , 2*MPPTs: 22.5A/15kW |
Operating Voltage Range (VDC) | 90Vdc~485Vdc |
Max PV Open Circuit Voltage (VDC) | 500Vdc |
Max PV Charge Current (A) | 160A |
Max AC Charge Current (A) | 160A |
Max. Charge Current (PV + AC) (A) | 160A |
Battery | |
Nominal Battery Voltage | 51.2VDC |
Rated Energy | 30KWh(0.5C , 25°C) |
Usable Energy(90%DOD) | 27KWh |
Max.Charge/Discharge Current | 200A/200A |
Operation Voltage Range | 44.8Vdc ~ 58.4Vdc |
Operation Temperature | -10°C ~ +50°C |
Interface | |
reveal | LCD |
communication | RS485 / RS232 / USB / Dry Contact |
Monitoring | WiFi |
General Protection | |
Ingress Protection | IP20 |
Operating Temperature | -10 °C ~ 50 °C |
Relative Humidity | 5% ~ 95% (Non-condensing) |
Storage Temperature | -15 °C ~ 60 °C |
Max. Operating Altitude | 4000m (Derating above 1000m) |
DIMENSION | |
L×W×H (products size, mm) | 695x298x1550mm |
L×W×H (package size, mm) | 755x480x1630mm |
